Insta360 Bike Computer Mount Integrated Handlebars ของแท้
Unlock new perspectives and take your cycling shots to new heights.
Available for both integrated and independent handlebars.
Effortlessly mount any Insta360 camera, bike light, and bike computer. Comes with a 1/4″ screw, 3-prong mount and bike computer base.
Compatible with bike computers from Garmin, Wahoo, Bryton, Giant, and more.
High-strength aluminum for stability every ride.
Bike Computer Mount.
More angles, cleaner setup, immersive footage.
Fresh perspectives.
Explore dynamic angles with third-person footage or thrilling POVs.
Keep it tidy.
Mount your camera, light and bike computer in one place and keep your handlebars clutter-free.
Built to last.
High-strength aluminum for reliable stability on every ride.
Custom fit.
Available for both integrated and independent handlebars.
Compatibility
X4
GO 3S
Insta360 Ace Pro
Insta360 Ace
GO 3
X3
ONE RS (Twin/4K)
GO 2
ONE X2
ONE R
ONE X
In the Box Bike Computer Mount (Integrated Handlebars)
1x Bike Computer Mount Main Piece
1x Thumb Screw
2x 18mm M5 Bolts
2x 18mm M4 Bolts
4x Anti-Slip Rings
1x 4mm Hex Wrench
1x 2mm Hex Wrench
1x Garmin Computer Mount
1x Wahoo Computer Mount
1x Bryton Computer Mount
1x Giant Computer Mount
2x Computer Mount Screws
Specs Bike Computer Mount (Integrated Handlebars)
Material:
Aluminum 7075-T6, plastic, stainless steel
Weight:
106g (3.7oz)
Dimensions:
187x39x33mm (7.4×1.5×1.3in)
ㆍSelect M5 bolts or M4 bolts according to the screw hole size of
the bike.
ㆍ The spacing between the screw holes of the Bike Computer
Mount is 9-55 mm. Adjust the Bike Computer Mount to the front
or rear positions on the handlebars according to the size of the
Bike Computer.
How to Use Bike Computer Mount (Integrated Handlebars)
1. Select a Computer Mount according to your model, then
install onto the Bike Computer Mount, and tighten the screws
with a 2mm Hex Wrench.
Tips:
ㆍThere are 2 mounting directions for a Computer Mount,
which can be installed on demand.
ㆍComes with 4 types of Computer Mount, suitable for many
kinds of Bike Computer, you can choose one of them on
demand.
2. Install the Bike Computer Mount to the front of the bike and
tighten the bolts with a 4mm Hex wrench.
Notes:
ㆍ Select M5 bolts or M4 bolts according to the screw hole size
of the bike.
ㆍThe spacing between the screw holes of the Bike Computer
Mount is 9-55 mm. Adjust the Bike Computer Mount to the
front or rear positions on the handlebars according to the size
of the Bike Computer.
ㆍ When tightening bolts, 5Nm is recommended, or according
to the recommended locking force value of the handlebars.
ㆍEnsure that the two bolts are both locked on the Bike
Computer Mount. If there is only one bolt on the handlebar, or
the screw spacing is not sufficient for the installation of the
Bike Computer Mount, do not use this part, as this may cause
the mount to fall.
9mm
55mm
3. Install the camera (or accessories such as a flashlight) on th
1/4″ screw or three-prong connector of the Bike Computer Mount.
Notes:
ㆍ If installed on the 1/4″ screw, it is recommended to use a
wrench to lock the mount firmly during installation.
ㆍIf the three-prong connector becomes loose after
installation, attach Anti-Slip Rings to the connector for
reinforcement.
ㆍThe angle of the three-prong connector can be adjusted after
loosening the screws on the base.
Screw
Three-prong connector
4. Install the Bike Computer on the Computer Mount.
Notes
1. Do not mount a selfie stick on this accessory. Mount the cameras directly.
2. When installing devices on this accessory, the maximum load is 500g (17.6oz). Do not
exceed this weight.
3. Before riding, check and confirm that all screws, bolts, and cameras are locked to
prevent issues.
4. It’s suggested to keep your speed within 60km/h (37 mph) on flat roads. It is not
recommended for use on bumpy roads.
